Features:
• Widely used for automatic welding of pipes and vessels.
• Each set composed of one power and one idler.
• Through a speed controller, you can realize speed variation continuously.
• Work piece rotates smoothly, ideal for manual welding, automatic pipe welding and automatic SAW welding etc.
• Forward-Stop-Reverse, Speed Control
• Foot Pendant
Specification:
Max drive capacity: 1000kg
Applicable work-pc Diameter: Φ 115 - 500mm
Rotation degree: ±360°xN
Wheel Diameter: Φ 250mm
Wheel linear speed: 200-2000mm/min
Motor power: 150W, DC90V, 1800rpm
Power: 220VAC±10%, 50Hz±1%, 0.3KW
Size (Lx W x H): Power 610 x 280 x 310mm
Weight: 50 kg+ 32kg
P/N: WE61000003
