ESAB Aristo 500ix – 3Ph, 400/415V

ARISTO® 500ix The Aristo 500ix is a portable heavy industrial pulse power source with robust and reliable mechanical design. Together with Robust Feed U6 or Pulse it is the perfect solution for demanding pulse applications. Aristo 500ix has thick metal side panels with double bent side panels and large feet providing clearance and making the unit fit for use in tough environments. The large side panels provide easy access for service and maintenance. Ergonomic handles that are safe and marked for crane lifting provide easy logistics. The unit comes with a sturdy cart featuring dedicated crane lifting points, a torch holder and large cable holders. FEATURES • Advanced pulse functionality reduces heat input and minimises spatter • Up to 250 pre-programmed synergic lines (U82 Plus) • QSetTM intelligent welding system • Crater filling, adjustable burn back time and SCT (short circuit termination) options for defect-free weld terminations • Durable and rugged –IP23 rating for outdoor and indoor use in rough environments • Compatible with Robust Feed Pulse U82 OS, rugged and portable feeder units with excellent feeding performance • MMA and gouging available from feeder WHAT IS QSET? Simply set the wire feed speed and the QSetTM function will automatically select the correct welding parameters for your wire/gas combination. QSetTM does this for all gas and wire combinations, CO2 and MAG Brazing alike and without any need for synergic lines on either of the control panels. QSetTM is the quick and easy way to finding optimized welding parameters for the best quality weld. Spatter and set-up time are reduced to a minimum. Applications • Industrial and General Fabrication • Structural Steel Fabrication • Steel Erectors • Marine and Offshore • Transportation • Railcars • Mobile Equipment • Tank and Vessel Fabrication • Pressure Vessels • Energy P/N: W1009725 Variation: W1009740, W1009725
